Industry Pipe Rotary Welding Positioners Welding Turning Table

Quick Details

• Conventional rotary welding positioners have universal applications in the manual and automatic welding of circumferential seams and in the accurate positioning of work-pieces;
• Free standing, robust all steel fabrication;
• Fully machined turntable of various sizes with centering grooves and T-slots;
• Main electric elements are ABB/Siemens brands;
• Hand pendant with Forward&Reverse Rotation, Tilt UP&DOWN, and speed potentiometer are standard;

1. Introduction

Conventional rotary welding positioners are designed for maximum loads of 5,000KG to 20,000KG have universal applications in the manual and automatic welding of circumferential seams and in the accurate positioning of work-pieces, and extensively applied in pressure vessel, metallurgy, power, chemical industry, metal structure and others lines.

We also provide tailor-made rotary welding positioners according to your special requirements.

2. Main Parameters

*We reserve the right to alter specifications without prior notice.

3. Main features

The standard models of our conventional rotary welding positioners have the following features:

• Free standing, robust all steel fabrication;
• Variable speed table rotation controlled by inverter;
• Motor with brake;
• Fully machined turntable of various sizes with centering grooves and T-slots;
• Sand blasting treatment to main welding parts before painting;
• All motion parts have lubrication system;
• Main electric elements are ABB/Siemens brands;
• Hand pendant with Forward&Reverse Rotation, Tilt UP&DOWN, and speed potentiometer are standard;
• Efficient built-in earthing;
• Lifting lug on the base of roller bed;
• Standard color:

Optional features:

• Square worktable;
• Extension arms;
• Extensive system accessories such as three-jaw chucks;
• Foot switch;
• Interface for integral control with welding column&boom;

4. Supply range

• Welding positioner (including machine frame, worktable, etc) 1set
• Electric control system (including 1piece of electric control cabinet, 1piece of remote control box and foot pedal with cable 6m] 1set
• Technical documents (with manual book, conformity certificate, packing list, etc) 1set

5. Reference drawing
