Hydraulic Edge Beveling Machine

China Hydraulic Edge Beveling Machine supplier
Hydraulic Edge Beveling Machine supplier Hydraulic Edge Beveling Machine supplier

Large Image :  Hydraulic Edge Beveling Machine

Product Details:

Place of Origin: China
Brand Name: Guoheng
Certification: CE, ISO9000
Model Number: DX series
OEM: Acceptable

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: Mainframe naked in container and electric control part packed in plywood case then in container
Delivery Time: 30days
Payment Terms: TT/LC
Supply Ability: 10sets/month
Price terms: FOB (Shanghai) or CIF (named port)
Contact Now
Detailed Product Description
High Light:

chamfering machine

,

plate beveling machine

Hydraulic Edge Beveling Machine



Quick Details



  • Used for H-beam, T-beam, Box-beam and cylinder end face milling to prepare the connection face;
  • The milling head is 0°--45° adjustable so as to mill the required bevels of end face of beams;
  • The bed is welding structure, annealed after welding;
  • Slide table is forged into shape, composing into sliding-couple with bed;
  • Standard facer available in any local market;
  • With work-piece hydraulic clamping and positioning rack;



1. Introduction



This machine is used for milling the end face of H-beam, box-beam and cylinder. The milling head is 0°--45° adjustable so as to mill the required bevels of end face of beams.



2. Main Parameters



Model

DX1215

DX1520

Suitable work-piece height (mm)

1200

1500

Suitable work-piece width (mm)

1500

2000

Milling head power (kW)

5.5

Vertical milling speed (mm/min)

55—500

Horizontal milling speed (mm/min)

50—440

Milling angle (°)

0°--45°

Power supply

AC380V, 50HZ, 3P or tailor made

Above are our standard models and parameters, and it can be designed and manufactured on request.


* We reserve the right to alter specifications without prior notice.



3. Main features



The standard models of our end face milling machines have the following features:

  • Robust all steel fabrication with stable structure and good rigidity, and no deformation after long time using;
  • The bed is welding structure, annealed after welding.
  • Facer is TX32A type, of reasonable structure, reliable performance, extensive speed range, good rigidity, low noise, high efficiency and convenient operation.
  • Slide table is forged into shape, composing into sliding-couple with bed;
  • Standard facer available in any local market;
  • With work-piece hydraulic clamping and positioning rack;
  • All motion parts have lubrication system;
  • Main electric elements are ABB/Siemens brands;
  • Standard color:



4. Structure drawing



Hydraulic Edge Beveling Machine



5. Reference photo

Hydraulic Edge Beveling Machine



6. Comparative advantage



  • ISO9000&CE certified;
  • International warranty;
  • Punctual delivery;
  • Professional and experienced engineer team to ensure the advanced design about structure and electric;
  • Experienced and skilled workers to care for each work flow from material cutting, welding, grinding to final assembly and testing to ensure high machine quality;
  • Professional and experienced after sale service team to guarantee quick and satisfied installation, commissioning or service;
  • Optimum materials and outsourcings to ensure the best performance;
  • Commissioning and testing before delivery;
  • Factory inspection is encouraged;
